Spray Booth Extraction Pleated Panel Filter 600x600mm/24" x 24"
24x24x2 Spray booth filters
SKU: SBF-2424-SGL
Pleated panel filters are medium efficiency, disposable filters suitable for heating, ventilation and air conditioning systems (HVAC). The filter is constructed from a high dust collecting G4 filter media which consists of non-woven cotton fibres that have been treated with flame retardant additives. These cotton fibres are then laminated onto a mesh backing and pleated to allow consistent airflow throughout the filter. Pleated panel filters come finished in a heavy duty cardboard frame box that has excellent resistance to tear when wet or dry.
Typically, airflow is at its lowest at the bottom of the pleat where contaminants are filtered out. The resistance at the bottom of the filter then increases as contaminants build up, resulting in airflow moving up the side of the pleat. This traps larger dirt particles at the back of the filter and the inertia prevents directional change. The smaller particles that are able to change direction are then trapped along the sides of the pleat. These filters provide an average energy efficiency saving of 30-35% and an arrestance of 93%.
Applications
Pleated panel filters are a popular option in food, drink and pharmaceutical industries where glass fibre is not permitted. They are used over glass or synthetic panel filters when a greater dust holding capacity is required.
This filter material is also commonly used in waste air and ventilation systems to filter coarse dust particles such as pollen and fog. They can also be used to protect against pollution in air conditioning or compact instruments. In public protection equipment they act as circulation filters can also be applied as a pre filters.
Key Features
Manufactured to EN 779 for dust air filters for general ventilation.
Heavy duty cardboard case with a G4 grade filter.
Commonly used in HVAC systems.
Up to 35% energy efficiency saving.
Average arrestance of 93%.
SKU: SBF-2424-SGL
Brand | Abacus |
---|---|
Size | 600 x 600 x 50mm |
